Customizable constant voltage ODM amplifiers

CV Series consist of multichannel 1RU rack direct drive constant voltage amplifiers, offering a high degree of customization and fast time to market as a turnkey solution including regulatory certifications.

Contact Pascal Sales
CV125.2 Specifications
Power Ratings (1% THD @ 120VAC and 230VAC) 4 Ω 8 Ω 70 V 100 V*
Single channel 250 W 250 W 250 W 250 W
All channels 125 W 125 W 125 W 125 W
  • Number of channels
  • 2
  • Dimensions, H x W x D
  • 44.5 x 220 x 262 mm (1.75 x 8.66 x 10.31 in)
  • Weight
  • 1.9 kg (4.2 lbs)
  • Output Circuitry
  • UMAC™ Class D - full bandwith PWM modulator with ultra low distortion
  • Output Voltage
  • 70 Vp / 140 Vpp (unloaded) / Bridged 140 Vp / 280 Vpp (unloaded)
  • Signal To Noise-Ratio
  • > 100 dB (A-weighted, 20 Hz - 20 kHz, 8 Ω load)
  • THD+N (typical)
  • < 0.05 % (20 Hz - 20 kHz, 8 Ω load, 3 dB below rated power)
  • Frequency Response
  • 20 Hz - 20 kHz (+0/-0.25 dB (8 Ω load, 3 dB below rated power)
  • Protection Circuits
  • Short circuit protection, DC protection, under voltage protection, temperature protection, overload protection
  • Power Supply
  • UREC™ universal mains switch mode power supply with Power Factor Correction (PFC) and integral standby converter
  • Operation Voltage
  • Universal Mains, 85-265V
  • Standby Consumption
  • < 0.5 W (Energy Star & ErP 1275/2008/EC compliant)
  • Accessories
  • 2x Rack ears • 1x 1/2 rack plate extension • 2x 1/2 rack mounting • 2x Rear supports
  • * 90 V RMS

    CV125.2 Features
    High Power Density & Flexibility

    CV Series offers market leading power density with up to 4 x 125 W constant voltage channels from a 1RU half rack format. Both high and low impedance outputs are available from same product, making this a flexible solution covering a very wide range of applications. For the half rack versions 250 W of power can be asymmetrically distributed per pair of output channels (i.e. 200 W + 50 W) enhancing the power flexibility even further.

    Highly Customizable

    For unique ID front plate panel mechanics and silkscreen can be customized. The Series also features manufacturer programmable DIP-switches, allowing for custom functionality and presets to match complementary manufacturers products. For high volume projects, custom designed network and DSP can be offered as a JDM solution.

    Turnkey Solution & Certification

    CV products are offered as a complete box build including cable, manuals and packaging ready to ship. Rack mounting accessories are also available. Furthermore, it comes with Energy Star, Safety and EMC certifications.

    Market Proven Reliability

    CV Series are based on Pascal ’s market proven amplifier designs, which are recognized for high reliability from more than a decade in the pro audio industry.

    Universal Mains & PFC

    Pascal’s UREC™ PFC (Power Factor Correction) power supply technology enables universal AC mains operation, eliminating the need for local market specific power regulation products and susceptibility to related reliability issues. The power supply delivers
    consistent, regulated power worldwide.

    Energy Star Compliant

    CV Series offer ultra low standby power consumption for EuP2013 and energy star compliance.
