IP500.4

Pascal’s customizable IP Series amplifiers combine Full Matrix DSP, many power & channel variants, optional Dante Ultimo 4x4 and AES67, speaker presets, intuitive control software, and open API for 3rd party control

Embedded Full-Matrix DSP
Fast installation with Intuitive control sw
Scalable: Hi-Z/Lo-Z & Power Sharing
Application-Specific Preset Libraries
Source control via Multizone Controller

Contact us

Features

Volume/source control via Pascal's Multizone Wall Controller
Use the IP Series with Pascal's Multizone Wall controller, which enables volume and source control in one or more rooms.
Application-Specific Speaker Preset Libraries
Integrated speaker presets with customizable EQ, crossover, and dynamics make deployment fast and consistent across sites.
Scalable to any Installation, Hi-Z/Lo-Z & Power Sharing
Available in 2, 4 and 8 channel configurations, with models scaling from 60W to 800W per channel. Bridge channels for Hi-Z, and share channel power for flexible setups.
Fast installation via wifi and intuitive control sw
Open the intuitive and customizable web gui control center for easy installation and management of all amplifiers connected to the network.
Embedded Full-Matrix DSP
Integrated DSP with FIR/IIR filters and full matrix routing enables powerful configuration directly via TCP/IP and built-in Wi-Fi access point.

Specifications

Audio & Channel Specifications

Audio Over IP (AoIP): None

Channels: 4

Performance Specifications

Frequency Response (±0.25dB, 8Ω load, 3dB below rated power): 20Hz-20kHz

Signal-to-Noise Ratio (A-weighted, 20Hz-20kHz, 8Ω load): >106dB

THD+N (typical, 20Hz-20kHz, 8Ω load, 3dB below rated power): < 0.05%

Physical Dimensions

Width: 440.0mm / 17.32"

Height: 88.0mm / 3.46"

Depth: 332.0mm / 12.68"

Weight: 16.3 lbs

Operating Conditions

Operating Temperature: 0°C to 40°C

Operating Voltage/Frequency: Universal Mains, 100V-240V, 50Hz-60Hz

Output Specifications

Output Circuitry: UMAC™ Class D - full bandwidth PWM modulator with ultra-low distortion

Output Power (100V, single channel driven): 1000

Output Power (4Ω, all channels driven): 500

Output Voltage (all channels, unloaded): 70Vp / 140Vpp

Output Voltage (bridged, unloaded): 140Vp / 280 Vpp

Power & Protection

Power Ratings (120VAC and 230VAC): 1% THD

Power Supply: UREC™ universal mains switch mode power supply with Power Factor Correction (PFC) and standby converter

Protection Circuits: Short circuit -, DC -, Undervoltage -, Temperature - and Overload protection
